Black PVC Insulation Copper PV Wire Water Resistant with Nylon Jacket 5.5mm

1
MOQ
Black PVC Insulation Copper PV Wire Water Resistant with Nylon Jacket 5.5mm
Features Gallery Product Description Request A Quote
Features
Specifications
Application: All
Jacket: Nylon
Product Name: Thhn Wire Cable
Color: Requirement
Certificate: ISO9001/ISO14001 /OHSAS18001/CCC
Standard: GB/T12706
Conductor: Copper
Insulation: PVC
Sheathed: Nylon
Keywords: Thhn Wire Cable 2.5mm 3.5mm 35mm 50mm 250mm
Voltage: 600V
Transport Package: Wooden Case/Plastic Film Case
Specification: Different Sizes And Specifications
Trademark: Golden Electric Or Customize
Origin: China
HS Code: 8543709990
Supply Ability: 5000/Month
Type: Insulated, Low Voltage
Conductor Material: Copper, Copper
Sheath Material: PVC
Insulation Material: PVC, PVC
Material Shape: Round Wire
Model Number: Thhn
Customization: Available | Customized Request
Highlight:

Black Copper PV Wire

,

PVC Insulation Copper PV Wire

,

Nylon Jacket Solar Panel Connecting Cables

Basic Infomation
Place of Origin: China
Brand Name: Golden Electric /OEM
Certification: ISO 9001, ISO 9000, ISO 14001, ISO 14000, ISO 20000, OHSAS/ OHSMS 18001, IATF16949
Payment & Shipping Terms
Packaging Details: Carton/Pallet
Delivery Time: Peak Season Lead Time: more than 12 months Off Season Lead Time: within 15 workdays
Payment Terms: LC, T/T, PayPal, Western Union
Supply Ability: 5000/Month
Product Description
Company Profile

GoldenElectricCo., Ltd.
is professional make of Electrical products .Such as distribution box, waterproof plug, socket, wall switch, waterproof plastic ,Aluminum box ,Changeover Switch and disconnecting switch,MC4 Connector.isolator switch.fusebreaker.distribution box,PV combiner box .surge protector, Indicator
lamp,Solar Charge Controller,Industrialplugandsocket,BusbarInsulator,Meter Socket,Wind Turbine, Terminal Block,Solar product and so on. all products comply with IEC, A S/NZS standard. passed CE, IP66, ROHS certificates.at present we have exported to many countries and have serve these customers with professional electrical solution.



Product Description

Black PVC Insulation Nylon Jacket Single Core 5.5mm 1/0 2/0 3/0 4/0 AWG Thhn Standard Copper Wire

Black PVC Insulation Nylon Jacket Single Core 5.5mm 1/0 2/0 3/0 4/0 AWG Thhn Standard Copper Wire

Black PVC Insulation Nylon Jacket Single Core 5.5mm 1/0 2/0 3/0 4/0 AWG Thhn Standard Copper Wire

Black PVC Insulation Nylon Jacket Single Core 5.5mm 1/0 2/0 3/0 4/0 AWG Thhn Standard Copper Wire

Black PVC Insulation Nylon Jacket Single Core 5.5mm 1/0 2/0 3/0 4/0 AWG Thhn Standard Copper Wire


Black PVC Insulation Nylon Jacket Single Core 5.5mm 1/0 2/0 3/0 4/0 AWG Thhn Standard Copper Wire

Black PVC Insulation Nylon Jacket Single Core 5.5mm 1/0 2/0 3/0 4/0 AWG Thhn Standard Copper Wire

Black PVC Insulation Nylon Jacket Single Core 5.5mm 1/0 2/0 3/0 4/0 AWG Thhn Standard Copper Wire



Products Details
Part Number
AWG Size
Conductor No./mm
Nom.O.D.(cm)
Nom.Insul.Thick.(cm)
Approx LBS/MFT
Ampacity@90ºC
THHN 14 1
14
Solid
0.26
0.04
15
15
THHN 14 19
14
19/0.38
0.28
0.04
16
15
THHN 12 1
12
Solid
0.30
0.04
23
20
THHN 12 19
12
19/0.47
0.33
0.04
24
20
THHN 10 1
10
Solid
0.41
0.05
38
30
THHN 10 19
10
19/0.60
0.41
0.05
38
30
THHN 8 19
8
19/0.75
0.54
0.08
63
55
THHN 6 19
6
19/0.95
0.63
0.08
95
75
THHN 4 19
4
19/1.19
0.81
0.10
152
95
THHN 3 19
3
19/1.33
0.88
0.10
189
110
THHN 2 19
2
19/1.50
0.96
0.10
234
130
THHN 1 19
1
19/.0664
1.10
0.13
299
150
THHN 1/0 19
1/0
19/1.68
1.20
0.13
372
170
THHN 2/0 19
2/0
19/1.89
1.32
0.13
462
195
THHN 4/0 19
4/0
19/2.67
1.58
0.13
718
260


Black PVC Insulation Nylon Jacket Single Core 5.5mm 1/0 2/0 3/0 4/0 AWG Thhn Standard Copper Wire

Black PVC Insulation Nylon Jacket Single Core 5.5mm 1/0 2/0 3/0 4/0 AWG Thhn Standard Copper Wire


Products Category
Black PVC Insulation Nylon Jacket Single Core 5.5mm 1/0 2/0 3/0 4/0 AWG Thhn Standard Copper Wire
Black PVC Insulation Nylon Jacket Single Core 5.5mm 1/0 2/0 3/0 4/0 AWG Thhn Standard Copper Wire
Protable Industrial Electrical Junxtion Boxes                    Buabsr Insulator With Low Voltage

Black PVC Insulation Nylon Jacket Single Core 5.5mm 1/0 2/0 3/0 4/0 AWG Thhn Standard Copper Wire
Black PVC Insulation Nylon Jacket Single Core 5.5mm 1/0 2/0 3/0 4/0 AWG Thhn Standard Copper Wire
Mc4 1Input 1 Output PV Cable Connector                          Automatic Recovery Over and Voltage Protector


Packing & Delivery

Packaging Details :
Inner packing:Wooden reel,Plastic reel,Paper reel
Ourter pakcing:Carton box,Pull outbox,Palleta available

Lead time:

Quantity(meters) 1 - 10000 >10000
Lead time (days) 7 To be negotiated

Black PVC Insulation Nylon Jacket Single Core 5.5mm 1/0 2/0 3/0 4/0 AWG Thhn Standard Copper Wire


FAQ

Q1: Are you a factory or trading company

A1: We are a factory, we can guarantee our price is first-hand, very cheap and competitive.
Q2: How does your factory do regarding quality control?
A2: All the products will be 100% checked before the shipment
Q3: When can I get the price?
A3:Usually we quote within 24 hours after we get your inquiry.
Q4: How could I get a sample?
A4: if you can not buy our product in your local area, we will ship a sample to you. You will be charged a sample price plus all related shipping costs. Express delivery charge depends on the quantity of the samples.
Q5: What is the price of shipping?
A5: Depending upon the port of delivery, prices vary.



                                                   Any more query please contact with us, thank you!
