The 10X38mm cylindrical fuse is one of the most common fuses in the industrial field. Chifeng fuses of this size can be made into gG, aM, aR and other fuses of different usage categories according to different application, and comply with the corresponding IEC60269-1, IEC6029-2 and IEC60269-4 standards.
Main Materials:
1. Body: ceramic material for electrical use.
2.Filling: quartz sand inside fulfils its function in a satisfactory manner.
3.Fuse element: copper
4.Size: Standard sizes according to the IEC Standard.
| Model Number | 10x38 fuse |
| Basic fuse size | 10x38mm |
| Ratings | |
| Voltage | 500V/690V |
| Current | 1-32A |
| Breaking Capacity | Up to 100kA |
| Operating class | gG/aM/aR |
Features & Benefits
Small size
Reliable performance
General purpose protection
Application
General cables
Motors protection
Semiconductor protection
Value service
Good After Sale Customer Service Quick & Professional Response
Short Production Cycle On Time Delivery
High Business Credibility
Other Hot-Selling Products
- Golden Electric Co.,Ltd ,was foundad in 2007, we are professional for make AC and DC electric items such as cable gland, isolator switch , fuse and fuse holder, Circuit breaker , distribution box , PV combiner box ,surge protector, Timer Switch,Industrial plug and socket,Wind Turbine, Solar product, busbar clamp and so on.
- Golden has been granted ISO9001 management system certifications. The comprehensive product line has more than 1000 models which have been approved by TUV,CE,CQC,SGS,ROHS,SASO. The productsells well to UK, Spain, Portugal, Singapore, Turkey, Russia, Korea, South Africa... more than 60 countries and regions.
- Golden is always striving hard to provide the best services and competitive price to all customers.
1)Q:How can i trust your company?
A:Golden electric is The top 10 manufacture in China - more than 350 Agents in local market and more than 100 foreign clients make OEM,ODM order from us,Golden electric is a big company, we have cooperation with LS, EKF the world-class companies. Our company over 100 employees, products pass CE,IEC,TUV,SAA, RCM, ROHS certificates.
2) Q:Your products?
A: Golden electric is factory for Circuit Breaker,Automatic transfer switch,Surge protector device,distribution box Enclosure, inverter, DC fuse, busbar clamp etc. Providing customers very competitive sources, and can be your sourcing agent in China. Goods are following international standards, IE, CE, ISO9001 ,SGS etc.
3) Q: Do you have forwarder?
A: Yes, we have good forwarder cooperated over 10 years, they help us import and export . For small package orders, suggest to use by Express.
4) Q: Your address ?
A: Locates in Guangzhou province, China,welcome to visit us
5) Q:What's the Fuse, Fuse holder guarantee?
A: 2 years warranty. If customer's problem, then customer burden. If our problem, then we send new goods to customer to replace asap.
6) Q:What's about MOQ? Delivery time ?
A: 1pcs for Fuse holder.
7) Q: What's the payment term?
A: Normally 100% T/T in advanced payment. If big order then about 50% advanced payment, balance before shipment.PAYPAL,WESTERN UNION,CASH for small order .
8) Q:What's your contact information ?
Send us your inquiry !we will reply you in 24 hours !
