Fixed Terminal Block Tb Series Tb- 1503 1506 1510 1512 2505 2512 4506 1006 and Durable

1
MOQ
Fixed Terminal Block Tb Series Tb- 1503 1506 1510 1512 2505 2512 4506 1006 and Durable
Features Gallery Product Description Request A Quote
Features
Specifications
Character: Environmental Protection
Production Process: Injection Molding
Brand: Golden Electric /OEM
Product Name: Barrier Terminal Blocks
Rated Voltage: 600V
Wire Range: 0.5-10mm2
Rated Current: 15A, 25A, 45A, 60A, 100A, 600A
Conductor Material: Copper
Base Material: Bakelite
Transparent Cover Material: As Resin
Insulation Resistance: 100mΩ
Transport Package: Standara Export Carton
Specification: 1-12P
Trademark: Golden Or Netural, Or Customer Brand
Origin: China
HS Code: 8536909000
Supply Ability: 20000PCS/Month
Application: PCB, Cable, Computer, Communication, Car, Battery
Environmental Protection: General
Connection Mode: Push-Pull Connection
Shape: Rectangle
Contact Termination Form: Screws Fixed
Type: Fixed Terminal
Customization: Available | Customized Request
Basic Infomation
Place of Origin: China
Brand Name: Golden Electric /OEM
Certification: ISO 9001, ISO 9000, ISO 14001, ISO 14000, ISO 20000, OHSAS/ OHSMS 18001, IATF16949
Document: Product Brochure PDF
Payment & Shipping Terms
Packaging Details: Carton/Pallet
Delivery Time: Peak Season Lead Time: more than 12 months Off Season Lead Time: within 15 workdays
Payment Terms: LC, T/T, PayPal, Western Union
Supply Ability: 5000/Month
Product Description

Product Description

This TB Series screw fixed barrier terminal block provides a simple way to connect wires to a single connection point. These blocks allow wires to be screwed together and self-isolated without needing to twist, solder or any other splicing, by this method wiring can adjusted at anytime just as easy as it was the first time.
Each position block offers a screw pitch of 10mm with a max current 15A /25A/45A/60A/100A and a max voltage tolerance of 600V before risking meltdown or implosion.Small pitch to save space, low structural height, Large wiring capacity, can be connected to the section area of 4mm² flexible wireThe plug socket is protected against wrong insertion and dislocation.








Product Features

Barrier Terminal Block Tb Series Tb- 1503 1506 1510 1512 2505 2512 4506 1006 Fixed Type Terminal
Black Bakelite Shell
High Quality Conductive Sheet
Barrier Terminal Block Tb Series Tb- 1503 1506 1510 1512 2505 2512 4506 1006 Fixed Type Terminal
Barrier Terminal Block Tb Series Tb- 1503 1506 1510 1512 2505 2512 4506 1006 Fixed Type Terminal
White Plated Screws
Dust Cover
Barrier Terminal Block Tb Series Tb- 1503 1506 1510 1512 2505 2512 4506 1006 Fixed Type Terminal













Product Parameters




Mode.No Wire Section Rated Current/Voltage Size(mm) Screws Poles
Length Wide High
TB-1503 0.5-1.5mm² 15A/600V 45.5 22 17.5 M3 3
TB-1504 0.5-1.5mm² 15A/600V 54.2 22 17.5 4
TB-1505 0.5-1.5mm² 15A/600V 63 22 17.5 5
TB-1506 0.5-1.5mm² 15A/600V 73 22 17.5 6
TB-1510 0.5-1.5mm² 15A/600V 107.5 22 17.5 10
TB-1512 0.5-1.5mm² 15A/600V 125.5 22 17.5 12
TB-2503 0.5-2.5mm² 25A/600V 55 30 19 M4 3
TB-2504 0.5-2.5mm² 25A/600V 67 30 19 4
TB-2505 0.5-2.5mm² 25A/600V 79 30 19 5
TB-2506 0.5-2.5mm² 25A/600V 91 30 19 6
TB-2510 0.5-2.5mm² 25A/600V 165 30 19 10
TB-2512 0.5-2.5mm² 25A/600V 163 30 19 12
TB-3503 0.5-2.5mm² 35A/600V 55 30 19 M4 3
TB-3504 0.5-2.5mm² 35A/600V 67 30 19 4
TB-3506 0.5-2.5mm² 35A/600V 91 30 19 5
TB-3512 0.5-2.5mm² 35A/600V 165 30 19 12
TB-4503 1.5-4mm² 45A/600V 70 38 23.5 M4 3
TB-4504 1.5-4mm² 45A/600V 86 38 23.5 4
TB-4505 1.5-4mm² 45A/600V 103 38 23.5 5
TB-4506 1.5-4mm² 45A/600V 120.5 38 23.5 6
TB-4512 1.5-4mm² 45A/600V 221 38 23.5 12
TB-60A/3P 2.5-6mm² 60A/600V 75 38 30.3 M6 3
TB-60A/4P 6P 12P 2.5-6mm² 60A/600V 92.7 38 30 4/6/12
TB-100A/3P 6P 12P 2.5-10mm² 100A/600V 86.3 43.5 34.5 M6 3/6/12









Product Details






Barrier Terminal Block Tb Series Tb- 1503 1506 1510 1512 2505 2512 4506 1006 Fixed Type Terminal


Barrier Terminal Block Tb Series Tb- 1503 1506 1510 1512 2505 2512 4506 1006 Fixed Type Terminal
Barrier Terminal Block Tb Series Tb- 1503 1506 1510 1512 2505 2512 4506 1006 Fixed Type Terminal
Barrier Terminal Block Tb Series Tb- 1503 1506 1510 1512 2505 2512 4506 1006 Fixed Type Terminal





Barrier Terminal Block Tb Series Tb- 1503 1506 1510 1512 2505 2512 4506 1006 Fixed Type Terminal






Recommand Product


Barrier Terminal Block Tb Series Tb- 1503 1506 1510 1512 2505 2512 4506 1006 Fixed Type Terminal







Company Profile

- Golden Electric Co.,Ltd ,was foundad in 2007, we are professional for make AC and DC electric items such as cable gland,MC4 Connector, isolator switch , fuse , breaker , distribution box , PV combiner box ,surge protector, Indicator lamp,Solar Charge Controller,Industrial plug and socket,Meter Socket,Wind Turbine, Terminal Block,Solar product and so on.


- Golden has been granted ISO9001 management system certifications. The comprehensive product line has more than 1000 models which have been approved by TUV,CE,CQC,SGS,ROHS,SASO. The productsells well to UK, Spain, Portugal, Singapore, Turkey, Russia, Korea, South Africa... more than 60 countries and regions.

- Golden is always striving hard to provide the best services and competitive price to all customers.








FAQ



1)Q:How can i trust your company?
    A:Golden electric is The top 10 manufacture in China - more than 350 Agents in local market and more than 100 foreign  clients make OEM,ODM order from us,Golden electric is a big company, we have cooperation with LS, EKF the world-class companies. Our company over 100 employees, products pass CE,IEC,TUV,SAA, RCM, ROHS certificates.
2) Q:Your products?
     A: Golden electric is factory for Automatic transfer swithc,Surge protector device,distribution box Enclosure, inverter, DC fuse etc. Providing customers very competitive sources, and can be your sourcing agent in China. Goods are following international standards, IE, CE, ISO9001 ,SGS etc.
3)  Q:   Do you have forwarder?
      A:   Yes, we have good forwarder cooperated over 10 years, they help us import and export . For small package orders, suggest to use by Express.
4)  Q:   Your address ?
      A:    Locates in Guangzhou province, China,welcome to visit us
5)  Q:What's the Barrier Terminal Block guarantee?
       A: 2 years warranty. If customer's problem, then customer burden. If our problem, then we send new goods to customer to replace asap.
6)  Q:What's about MOQ? Delivery time ?
      A: 1pcs for Barrier Terminal Block.
7)  Q: What's the payment term?
       A: Normally 100% T/T in advanced payment. If big order then about 50% advanced payment, balance before shipment.PAYPAL,WESTERN UNION,CASH for small order .
8)   Q:What's your contact information ?
Send us your inquiry !we will reply you in 24 hours !

If you need information about this product. Please Click here to contact me and we will provide you with more information about the products.
