Finished Tin Plated Aluminum Alloy Mechanical Lug Aul Bolted Type Shear Head Connector

Finished Tin Plated Aluminum Alloy Mechanical Lug Aul Bolted Type Shear Head Connector

Brand Name: Golden Electric /OEM
MOQ: 1
Payment Terms: LC, T/T, PayPal, Western Union
Supply Ability: 5000/Month
Detail Information
Place of Origin:
China
Certification:
ISO 9001, ISO 9000, ISO 14001, ISO 14000, ISO 20000, OHSAS/ OHSMS 18001, IATF16949
Model NO.:
AUL
Interface Type:
Bolted Type
Entry:
Chamfered Entry
Coating:
Tin
OEM:
Accept
Sample:
Accept
Color:
Natural
Product Key Words:
Insulated Terminal Blocks
Finished:
Tin Plated
Transport Package:
Standard Export Carton
Specification:
Aluminum Alloy
Trademark:
Golden Or Netural Or Customer Brand
Origin:
China
HS Code:
8547200000
Supply Ability:
500000PCS/Month
Material:
Aluminum
Application:
Conduct Electricity
Character:
Insulation
Species:
Terminal
Production Process:
Injection Molding
Shape:
Tubular
Samples:
US$ 0.5/Piece 1 Piece(Min.Order) | Request Sa
Customization:
Available | Customized Request
Packaging Details:
Carton/Pallet
Supply Ability:
5000/Month
Product Description

Product Description

Finished Tin Plated Aluminum Alloy Mechanical Lug Aul Bolted Type Shear Head Connector 0

Product Description

AUL Bolted Type Shear Head Connector Aluminum Alloy Mechanical Lug


Technical Requirements
Material:

Aluminium alloy

Surface treatment:
Acid cleaning or tin plated

Product property:
It use spanner instead of hydraulic tool to finish installation.The special eccentric design for round conductor ensures enough anti-wrench strength and conductivity.The bolt has two shear ends A and B(Note:A is shorter than B). The boltsand nuts are specially designed to install on large range of conductors.When installing,you can choose the suitable end and tighten it until it breaks.The barrel capped is filled with joint compound to avoid oxidization.and its type test is in accordance with IEC61238-1.

Finished Tin Plated Aluminum Alloy Mechanical Lug Aul Bolted Type Shear Head Connector 1

Product Parameters

Finished Tin Plated Aluminum Alloy Mechanical Lug Aul Bolted Type Shear Head Connector 2


Type Conductor Cross-section(mm2) Shear Head A or B Number of Bolts
AUL16-70-12 16-35
50-70
B
A
2
AUL95-150-12 95-120
150
B
A
2
AUL185-240-16 185
240
B
A
2

Packaging & Shipping

Terminal Value Of Packaging

Finished Tin Plated Aluminum Alloy Mechanical Lug Aul Bolted Type Shear Head Connector 3
Finished Tin Plated Aluminum Alloy Mechanical Lug Aul Bolted Type Shear Head Connector 4

Packaging Details:

Customized Packing: Header card packing, Blister with card packing, Double blister packing, Canister packing, other
packing can be supplied according customers request.


Shipping:
1. By Air or by Sea for batch goods,Airport/ Port receiving;
2. Customers specifying freight forwarders or negotiable shipping methods!


Delivery Detail:
Shipped in 7 days after payment
