Customized Applications Electrical Power Copper Wire with Insulation Material PVC

1
MOQ
Customized Applications Electrical Power Copper Wire with Insulation Material PVC
Features Gallery Product Description Request A Quote
Features
Specifications
Brand: Blj
Type: Bare, Low Voltage
Conductor Material: ["Copper","Pure Copper Or Copper Clad Steel"]
Conductor Type: Stranded
Categories: Power Cables
Nos Of Conductors: 7,19,37nos
Manufacturer: Yes
Suppliers By Country: China
Transport Package: Ocean Freight Woven Belt+ Wooden Case+ Pallets+ C
Trademark: Golden Electric Or Customize
Origin: China
HS Code: 7413000000
Supply Ability: 5000/Month
Application: Construction, Underground, Underground, Construction
Voltage: Low And Medium Voltage Cable
Insulation Material: PVC, PVC
Sheath Material: PVC
Material Shape: Round Wire
Wire Core Material: Bare Copper Wire
Customization: Available | Customized Request
Basic Infomation
Place of Origin: China
Brand Name: Golden Electric /OEM
Certification: ISO 9001, ISO 9000, ISO 14001, ISO 14000, ISO 20000, OHSAS/ OHSMS 18001, IATF16949
Model Number: BV
Payment & Shipping Terms
Packaging Details: Carton/Pallet
Delivery Time: Peak Season Lead Time: more than 12 months Off Season Lead Time: within 15 workdays
Payment Terms: LC, T/T, PayPal, Western Union
Supply Ability: 5000/Month
Product Description
Company Profile

GoldenElectricCo., Ltd.
is professional make of Electrical products .Such as distribution box, waterproof plug, socket, wall switch, waterproof plastic ,Aluminum box ,Changeover Switch and disconnecting switch,MC4 Connector.isolator switch.fusebreaker.distribution box,PV combiner box .surge protector, Indicator
lamp,Solar Charge Controller,Industrialplugandsocket,BusbarInsulator,Meter Socket,Wind Turbine, Terminal Block,Solar product and so on. all products comply with IEC, A S/NZS standard. passed CE, IP66, ROHS certificates.at present we have exported to many countries and have serve these customers with professional electrical solution.


Product Description

Low Cost Electrical Power Insulated Winding Copper Wire

Material
99.9%pure copper
Diameter
10-400 mm²
Life
≥50 years
Voltage grade
450/750V
Characters
Easy installation ,Good conductivity
Available service mode
OEM,ODM
Certificate
ISO9001:2015
Regular Products size(We Accept Customization)
Negotiable Price According to different material/size and and Purchase quantity
Product specifications
Nos/Dia
(pcs/mm)
Outer Dia
(mm)
Weight
(kg/km)
BV 16
7/1.70
8.0
179
BV 25
7/2.14
10.0
281
BV 35
7/2.52
11.5
381
BV 50
19/1.78
13.0
521
BV 70
19/2.14
15.0
734
BV 95
19/2.52
17.5
962
BV 120
37/2.03
19.0
1180
BV 150
37/2.25
21.0
1470
BV 185
37/2.52
23.5
1810

Low Cost Electrical Power Insulated Winding Copper Wire

Low Cost Electrical Power Insulated Winding Copper Wire

Low Cost Electrical Power Insulated Winding Copper Wire

Low Cost Electrical Power Insulated Winding Copper Wire

Low Cost Electrical Power Insulated Winding Copper Wire

Low Cost Electrical Power Insulated Winding Copper Wire

Low Cost Electrical Power Insulated Winding Copper Wire
      The Insulated Copper Conductor is used as flexible connector in electric transmission and distribution appliance (such as volt transformer, electric stove),electronic equipment and thyristor. Green Yellow Grounding Wire also could be used for grounding wire in electric working. Also, it can be manufactured according to customer's drawings and demands.
      Insulated Copper Conductor is used for earthing system of power plant ,transformer station ,tower ,communication station ,airport, railway, subway station , high building ,computer room ,petro plant ,oil reservoir in the environmental of moist ,saline and alkaline ,acid and chemical corrosion medium environmental.

Products Category
Low Cost Electrical Power Insulated Winding Copper Wire
Low Cost Electrical Power Insulated Winding Copper Wire

                Industrial Plug Socket Connector                                                    Metal Electrical Distribution Box

Low Cost Electrical Power Insulated Winding Copper Wire
Low Cost Electrical Power Insulated Winding Copper Wire
ATS Automatic Transfer Switch Panel Box of Generator                                  Changeover Cam Rotary Switch

Packing & Delivery

Packaging Details:  woven belt+ wooden case+ pallets+ container

Lead time:

Quantity(meters) 1 - 1000 1001 - 10000 >10000
Lead time (days) 15 30 To be negotiated

Low Cost Electrical Power Insulated Winding Copper Wire

FAQ

Q1: Are you a factory or trading company
A1: We are a factory, we can guarantee our price is first-hand, very cheap and competitive.
Q2: How does your factory do regarding quality control?
A2: All the products will be 100% checked before the shipment
Q3: When can I get the price?
A3:Usually we quote within 24 hours after we get your inquiry.
Q4: How could I get a sample?
A4: if you can not buy our product in your local area, we will ship a sample to you. You will be charged a sample price plus all related shipping costs. Express delivery charge depends on the quantity of the samples.
Q5: What is the price of shipping?
A5: Depending upon the port of delivery, prices vary.



                                 Any more query please contact with us, thank you!
