DC/DC Interface Type PV Mc004-3t1 PV Solar Connectors 1000V/30A PV004-D Match with Mc4

1
MOQ
DC/DC Interface Type PV Mc004-3t1 PV Solar Connectors 1000V/30A PV004-D Match with Mc4
Features Gallery Product Description Request A Quote
Features
Specifications
Model NO.: GD-IP67
Contact Resistance: Below 5m
Rated Voltage: 1000V(TUV),600V(UL)
Rated Current: 25A/30A/45A/80A Optioanl
Warranty: 2 Year
Model No.: PV Mc004-3t1
Shape: Round
Transport Package: Standard Export Carton
Specification: 2.5/4/6 14/12/10AWG
Trademark: Golden Electric Or Customize
Origin: China
HS Code: 8537209000
Supply Ability: 5000/Month
Application: Power
Certification: CE
Terminal Material: Copper
Interface Type: DC/DC
Housing Material: PPO
Flame Class: UL94V-0
Samples: US$ 0.8/Piece 1 Piece(Min.Order) | Request Sa
Customization: Available | Customized Request
Basic Infomation
Place of Origin: China
Brand Name: Golden Electric /OEM
Certification: ISO 9001, ISO 9000, ISO 14001, ISO 14000, ISO 20000, OHSAS/ OHSMS 18001, IATF16949
Document: Product Brochure PDF
Payment & Shipping Terms
Packaging Details: Carton/Pallet
Delivery Time: Peak Season Lead Time: more than 12 months Off Season Lead Time: within 15 workdays
Payment Terms: LC, T/T, PayPal, Western Union
Supply Ability: 5000/Month
Product Description


Product Description

MC-4 Solar Panel Cable Connectors with Assembly Tool,10 Pairs Copper Solar Wire Adapter Male/Female Waterproof Connector for Connecting Solar Panels 1000V 30A

Features


1.Load Capability with big current and high voltage
2.Lower contact resistance
3.Desugn of waterproof and dustproof
4.Excellent performances of high-low temperature,fireproof ,anti-ultraviolet

Product Parameters



Type PV-004-D
Rated Voltage 1000V DC/1500V DC
 Contact  resistance <1mΩ

 Rated current:

 30A/50A
 Temperature  range  -40ºC ~ +85ºC

 Contact material

  Copper,tin plated

Insulation Voltage

 6000V
Fire-proof level UL94-V0

Details display



The head
Similar to the male MC4 connector, high-strength waterproof ring, waterproof level reaches IP67
DC/DC Interface Type PV Mc004-3t1 PV Solar Connectors 1000V/30A PV004-D Match with Mc4 0

DC/DC Interface Type PV Mc004-3t1 PV Solar Connectors 1000V/30A PV004-D Match with Mc4 1
Solid in the middle and can be engraved with standard voltage and current ratings



Similar to MC4 female connector, for safe docking
DC/DC Interface Type PV Mc004-3t1 PV Solar Connectors 1000V/30A PV004-D Match with Mc4 2

Drawings

DC/DC Interface Type PV Mc004-3t1 PV Solar Connectors 1000V/30A PV004-D Match with Mc4 3



Application field

Applied to solar amorphous silicon module power generation projects, household roofs, greenhouse farming, fish farm farming, traffic lights, parking lot charging stations, commercial buildings, deep water well drinking/irrigation, etc.
DC/DC Interface Type PV Mc004-3t1 PV Solar Connectors 1000V/30A PV004-D Match with Mc4 4

Other Hot-Selling Models



DC/DC Interface Type PV Mc004-3t1 PV Solar Connectors 1000V/30A PV004-D Match with Mc4 5The Delivery time and shipping of MC4 solar cable connector
Deilivery time:
1-7 days after confirming order
Shipping:
1. Shipment port:GUANGZHOU
2. By Air or by Sea for batch goods,Airport/ Port receiving;
3. Customers specifying freight forwarders
