Copper IP67 Waterproof Solar Y Branch Connectors With Lightning Protection

1
MOQ
Copper IP67 Waterproof Solar Y Branch Connectors With Lightning Protection
Features Gallery Product Description Request A Quote
Features
Specifications
Model NO.: PV004-2T1
Product Name: Mc4 Solar Connector
Rated Voltage: 1000V
Rated Current: 30A
Shape: Round
Protection Degree: IP67
Connector Type: Adaptor
Warranty: 2 Years
Contact Resistance: Below 5m
Name: Solar Cable Connector
Transport Package: Standard Export Carton
Specification: 2.5/4/6 14/12/10AWG
Trademark: Golden Or Netural, Or Customer Brand
Origin: China
HS Code: 8537209000
Supply Ability: 20000PCS/Month
Gender: Male And Female
Pin: 2 Pins
Application: Solar PV System
Certification: YUV, MSDS, CE, ISO 9001, RoHS
Terminal Material: Copper
Interface Type: DC/DC
Customization: Available | Customized Request
Highlight:

Waterproof Solar Y Branch Connectors

,

Copper Solar Y Branch Connectors

,

Waterproof 2 In 1 Mc4 Connector
Basic Infomation
Place of Origin: China
Brand Name: Golden Electric /OEM
Certification: ISO 9001, ISO 9000, ISO 14001, ISO 14000, ISO 20000, OHSAS/ OHSMS 18001, IATF16949
Model Number: PV004
Document: Product Brochure PDF
Payment & Shipping Terms
Packaging Details: Carton/Pallet
Delivery Time: Peak Season Lead Time: more than 12 months Off Season Lead Time: within 15 workdays
Payment Terms: LC, T/T, PayPal, Western Union
Supply Ability: 5000/Month
Product Description

Product Description


MC4 Solar Panel Cable Connectors with Assembly Tool,10 Pairs Copper Solar Wire Adapter Male/Female Waterproof Connector for Connecting Solar Panels 1000V 30A.

Possess excellent resistance to high temperature, fire protection, anti-aging and anti-UV properties, to meet the outdoor longterm use under harsh environmental conditions require.

Excellent sealing performance, waterproof and dustproof rating up to IP67.
Male and female head swap with a self-locking, electrical connections fully reliable, open and close freely.
Has broad applicability, can be inserted with the MC4 and match each other completely.



Product Features

IP67 Waterproof PV Solar Branch Connector 2 to 1 Male and Female Cable Y Type Mc4 Solar PV Connectors
High Quality Raw Material PPO,PC

Approved by TUV and CE certification, high heat resistance, wear resistance, pollution resistance, strong toughness.
Tinned Plated Copper Inner Core

Open core,wear resistance, corrosion resistance, prevent rust.
IP67 Waterproof PV Solar Branch Connector 2 to 1 Male and Female Cable Y Type Mc4 Solar PV Connectors
IP67 Waterproof PV Solar Branch Connector 2 to 1 Male and Female Cable Y Type Mc4 Solar PV Connectors
High Strength Waterproof Ring

Dustproof, Waterproof, Protection degree IP67
Stable Self - Locking Structure

The joint adopts compression and fastening mode, the male and female head has self-locking structure to open and close freely .
IP67 Waterproof PV Solar Branch Connector 2 to 1 Male and Female Cable Y Type Mc4 Solar PV Connectors
IP67 Waterproof PV Solar Branch Connector 2 to 1 Male and Female Cable Y Type Mc4 Solar PV Connectors
 Insulation Waterproof

Built-in high quality lock head, delicate, firm, sealed, insulating, to guide and prevent electric shock.




Product Parameters

Technical Data
Type PV004-2to1
Rated Voltage 1000VDC
Rated impulse voltage 8000V
Rated insulation voltage 6000V
Rated Current 10A,20A
Standard EN50521:11-2008
Protection Degree IP67
Contact Resistance ≤5mΩ
Pollution Degree 2
Ambient Temperature -40~+85°C
Cable cross section area  4,0 mm²
Insulation Material PC EXL9330
Flame Class UL94-V0





Product Details

IP67 Waterproof PV Solar Branch Connector 2 to 1 Male and Female Cable Y Type Mc4 Solar PV Connectors

IP67 Waterproof PV Solar Branch Connector 2 to 1 Male and Female Cable Y Type Mc4 Solar PV ConnectorsIP67 Waterproof PV Solar Branch Connector 2 to 1 Male and Female Cable Y Type Mc4 Solar PV Connectors




Recommand Product

IP67 Waterproof PV Solar Branch Connector 2 to 1 Male and Female Cable Y Type Mc4 Solar PV Connectors

IP67 Waterproof PV Solar Branch Connector 2 to 1 Male and Female Cable Y Type Mc4 Solar PV Connectors
IP67 Waterproof PV Solar Branch Connector 2 to 1 Male and Female Cable Y Type Mc4 Solar PV Connectors
IP67 Waterproof PV Solar Branch Connector 2 to 1 Male and Female Cable Y Type Mc4 Solar PV Connectors






Company Profile


- Golden Electric Co.,Ltd ,was foundad in 2007, we are professional for make AC and DC electric items such as cable gland,MC4 Connector, isolator switch , fuse , breaker , distribution box , PV combiner box ,surge protector, Indicator lamp,Solar Charge Controller,Industrial plug and socket,Wind Turbine, Solar product and so on.

- Golden has been granted ISO9001 management system certifications. The comprehensive product line has more than 1000 models which have been approved by TUV,CE,CQC,SGS,ROHS,SASO. The productsells well to UK, Spain, Portugal, Singapore, Turkey, Russia, Korea, South Africa... more than 60 countries and regions.

- Golden is always striving hard to provide the best services and competitive price to all customers.






FAQ


1)Q:How can i trust your company?
    A:Golden electric is The top 10 manufacture in China - more than 350 Agents in local market and more than 100 foreign  clients make OEM,ODM order from us,Golden electric is a big company, we have cooperation with LS, EKF the world-class companies. Our company over 100 employees, products pass CE,IEC,TUV,SAA, RCM, ROHS certificates.
2) Q:Your products?
     A: Golden electric is factory for Automatic transfer swithc,Surge protector device,distribution box Enclosure, inverter, DC fuse etc. Providing customers very competitive sources, and can be your sourcing agent in China. Goods are following international standards, IE, CE, ISO9001 ,SGS etc.
3)  Q:   Do you have forwarder?
      A:   Yes, we have good forwarder cooperated over 10 years, they help us import and export . For small package orders, suggest to use by Express.
4)  Q:   Your address ?
      A:    Locates in Guangzhou province, China,welcome to visit us
5)  Q:What's the MC4 connector guarantee?
       A: 2 years warranty. If customer's problem, then customer burden. If our problem, then we send new goods to customer to replace asap.
6)  Q:What's about MOQ? Delivery time ?
      A: 1pcs for MC4 Connector.
7)  Q: What's the payment term?
       A: Normally 100% T/T in advanced payment. If big order then about 50% advanced payment, balance before shipment.PAYPAL,WESTERN UNION,CASH for small order .
8)   Q:What's your contact information ?
Send us your inquiry !we will reply you in 24 hours !
