| Brand Name: | Golden Electric /OEM |
| MOQ: | 1 |
| Payment Terms: | LC, T/T, PayPal, Western Union |
| Supply Ability: | 5000/Month |
| Model | AVIV-M 1200 | AVIV-M 2400 |
| Power Rating | 1200VA/900W | 2400VA/1600W |
| Input | ||
| Voltage | 230VAC | |
| Optional voltage range | 90-280VAC | |
| Frequency range | 50Hz/60Hz( auto-induction ) | |
| Output | ||
| AC voltage regulation(Battery mode) | 230VAC+10% | |
| Overload(Line mode) | Load> 110% ± 15%, if the user lowers the load, alarm 5 times and then fail Load <100% rating, overload alarm release.Loaded> 130% ± 15%, immediate failure | |
| Efficiency(Peak) | 82% | 85% |
| Time of transmission | 20ms | |
| Wave form | Simulated sine waves | |
| Battery | ||
| Battery voltage | 12VDC | 24VDC |
| Floating charge voltage | 13.7VDC±0.5VDC | 27.4VDC±1VDC |
| Overcharge protection | 15VDC±0.5VDC | 30VDC±1VDC |
| Solar Chargers & AC Chargers | ||
| Solar power charger type | MPPT | |
| Peak PV array open-circuit voltage | 100VDC | |
| Peak PV array power | 600W | 1200W |
| MPPT Range working voltage | 15~80VDC | 30~80VDC |
| Peak solar charging current | 50A | |
| Peak AC charging current | 10A/20A | 15A |
| Peak charging current | 50A | |
| Indicator lamp | AC mode, battery mode, fault | |
| Alarm | Low battery power, overload, fault | |
| Size | ||
| Length x width x height | 290x232x93mm | |
| Net Weight | 4.5kg | |
| Operating Environment | ||
| Humidity | 0-90% relative humidity(No condensation) | |
| Working temperature | 0°C - 40°C | |
| Storage temperature | -15°C - 50°C | |
